Toyota 22R-E User Manual

SERVICE SPECIFICATIONS
SERVICE DATA
At idle speed (normal operating temperature)
At 3,000 rpm (normal operating temperature)
TORQUE SPECIFICATIONS
Oil pressure sender gauge x Cylinder block
STD
Limit
STD
Limit
STD
Limit
Oil pump x Oil pump body cover
Relief valve operating pressure
Oil strainer x Cylinder block
Oil pump x Cylinder block
Oil cooler x Cylinder block
Oil pan x Cylinder block
Oil pump x Relief valve
Oil cooler x Relief valve
Body clearance
Part tightened
Tip clearance
Side clearance
Oil pressure
Oil pump
–ENGINE LUBRICATION SYSTEM
EG2–291

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
