3. Measure the pump body clearance using feeler
gauges.
Body Clearance
3.
Fit the oil pump to the crankcase, ensure the
water pump drive peg locates into the drive on
the water pump shaft. Tighten the bolts to
13.7
Nm.
Standard:
Service limit:
5. (a) If all clearances are within service limits,
liberally apply clean engine oil to all internal
components and refit the oil pump plate to the oil
pump body.
0.1 5
-
0.22 mm
0.35 mm
Standard:
Service limit:
(b) If any clearance measured is outside the
service limits, renew the complete pump.
4.
Measure the pump end clearance.
Pump End Clearance
0.02
-
0.07 mm
0.10 mm
6.
Inspect all the sprocket and chain for wear andlor
damage. Replace the sprocket and chain if wear
and/or damage is found.
Installation
I
Before fitting the oil pump to the crankcase ensure
I
I
the pump internal surfaces have been 'wetted' with
I
dean engine oil. The pump-may fail to pickup oil-
from the sump if the surfaces have not been
'wetted'. This will cause the engine to run without
engine oil pressure and will lead to severe engine
damage.
1.
Fill the oil pump with new engine oil, turning the
pump rotor as the
oil is poured in to ensure all
surfaces are coated with oil.
2. Position the oil pump to the crankcase and insert
into the opening provided.
Note:
Use the sprocket end of the oil pump shaft
to turn the drive peg into alignment with
the drive on the water pump.
Pump Insertion
4.
As an assembly, slide the upper drive sprocket
bearing, upper drive sprocket, drive chain and
pump sprocket onto the input shaft and oil pump.
1. Oil pump drive chain
2.
Pump drive sprocket fixing
3. Pump drive sprocket
4.
Tool T3880371
5.
Locate the pump drive sprocket onto the pump
ensuring that the drive engages correctly.
6.
Refit tool T3880371 to the upper drive sprocket
and tighten a new oil pump drive sprocket centre
bolt to
15
Nm.
Remove the tool.
7. Assemble the clutch (see page
4-9).
8.
Reconnect the battery, positive (red lead) first.
9.
Refill the engine with oil (see page
8-7).
