Electrical
Starter Motor
Installation
Removal
1.
Remove the seats (see page
16-8).
2.
Disconnect the battery negative (black) lead first.
3.
Remove the fuel tank (se page
10-88).
4.
Remove the low oil pressure warning light switch
(see page
8-1
1).
5.
Ease the boot from the starter cable and then
release the cable nut.
6.
Detach the cable.
7.
Release the bolts securing the starter to the
crankcase.
1.
Starter motor
2.
Bolts
8.
Ease the starter motor from the right hand
engine cover while gently moving the camshaft
oil feed pipe out of the way.
Inspection
1.
Ensure the starter turns freely and without
Fit the starter motor to the right hand engine
cover ensuring that the '0' ring does not become
damaged during installation.
Fit and tighten the starter bolts to
10
Nm.
Refit the lead and secure with the nut. Tighten to
7
Nm.
Refit the lead boot.
Refit the low oil pressure warning light switch
(see page
8-1
1).
Refit the fuel tank.
Reconnect the battery positive (red) lead first.
Refit the seat (see page
16-9).
Alternator
Removal
1.
Remove the seats (see page
16-8).
2.
Disconnect the battery negative (black) lead first.
3.
Release the bolts securing the left hand
crankshaft cover to the engine.
binding.
1.
Left hand engine cover
2'
Check
the
'O'
ring
for
damage
and
4. Withdraw the cover from the crankcase against
deterioration. Replace as necessary.
the pull of the alternator magnet.
Service Manual
-
Speed Triple
