Unify CP200 User Manual

157
Diagnostic data
This information overview in the user area of the service menu provides you with
information on the current configuration of the telephone:
@ Press the key shown.
Select and confirm the option shown.
if nec. j Enter and confirm the user password.
Select and confirm the option shown.
You see a numbered list of telephone parameters with the current settings.
You can see a more structured view of the list via the WEB interface
 page 160:
Example:
User
Diagnostic information
Diagnostic.information
2016-04-25 06:48:1
00 Terminal number 3338
01 SIP server 192.168.1.230
02 SIP port 5060
03 SIP registrar 192.168.1.230
04 SIP registrar port 5060
05 SIP gateway 192.168.1.230
06 SIP gateway port 5060
07 SIP transport UDP
08 TLS renegotiation Secure (RFC5746)
09 SIP local port 5060
10 Server features No
11 DNS results None
12 MultiLine No
13 Keyset Lines None
14 Backup active Yes
15 Backup proxy None
16 Use secure calls No
17 SRTP.Status Disabled
18 SIP server cert. check No certificate check
19 Software version V0R1.1.1 SIP 160414
20 Display message Telephony failed (RF2)
21 Last restart 2016-04-22T06:36:56
22 Memory free 68009K free
23 Protocol mode IPv4_IPv6
24 IPv4 address 192.168.1.243
25 IPv4 subnet mask 255.255.255.0
26 IPv4 default route 192.168.1.2
