G 25 Technical Data

20.2 Generator

Machine

G 25

G 25 ERT

Generator

Make/Type Mecc Alte / Brushless

Model ECO 28-2LN/4

Generator speed rpm 1800

Voltage selector switch 3 position

AC voltages available 120/240 zig-zag

120/208 low-wye

277/480 hi-wye

Frequency 60 Hz

Power factor 1ø

3ø

1.0

0.8

Voltage regulation ±1.00%

Insulation class H

Sound level at 7 m (23 ft.) db(A) 65

AC receptacles 2 duplex, 2 twist-lock

1ø 120 GFI duplex A 2-20A

1ø 120/240 V twist lock A 2-50A

(1-20A optional)

(1-30A optional)

Standby output kW/kVA 20.4/25.5

Continuous output kW/kVA 19.5/24.4
