Technical Data G 25

20.3 Trailer and Skid

With Tier 4i Isuzu engine

With Tier 4f Isuzu engine

Machine G 25 G 25 ERT

Trailer and Skid

Dry weight of skid kg (lb) 867 (1911) 950 (2094)

Operating weight of skid kg (lb) 1,058 (2333) 1,372 (3026)

Trailer weight kg (lb) 182 (400) 290 (640)

GVWR kg (lb) 1,338 (2,995)

Surge brakes fluid type DOT3

Tires size ST205/75D-15C

Machine G 25 G 25 ERT

Trailer and Skid

Dry weight of skid kg (lb) 885 (1,952) 969 (2,136)

Operating weight of skid kg (lb) 1,076 (2,373) 1,391 (3,068)

Trailer weight kg (lb) 182 (400) 290 (640)

GVWR kg (lb) 1,338 (2,995)

Surge brakes fluid type DOT3

Tires size ST205/75D-15C
