Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-61
Toner Cartridge and Drum Cartridge Errors
CAUTION: Over exposure to light reduces OPC drum sensitivity. After removal, cover the Toner
Cartridge and Drum Cartridge to block light reaching the OPC Drum.
Toner Low
The Toner Cartridge is almost empty. Toner may be low or be unevenly distributed.
Applicable Error
• 09-100: Toner Low
Initial Actions
• Turn the printer off and then on again.
• If the problem persists continue troubleshooting.
Troubleshooting Reference Table.
Applicable Parts Wiring and Plug/Jack Map Reference
• Toner Cartridge and Drum Cartridge, See
Xerox Supplies and Accessories
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
To Next Page
