General Information
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
1-12
Parts of the Printer
Phaser 3330 Front View
No. Description No. Description
1. Paper Level Indicators 6. Output Tray Support
2. Optional Tray 2 (550 Sheets) 7. LCD Display
3. Tray 1 (250 Sheets) 8. USB Cable Port
4. Bypass Tray and Extension 9. Control Board Cover
5. Output Tray
