General Information
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
1-2
About this Service Manual
The Phaser 3330 and WorkCentre 3335/3345 Service Manual is the primary document used for
repairing, maintaining, and troubleshooting the printer. Use this manual as your primary resource for
understanding the operational characteristics of the printer and all available options. This manual
describes specifications, diagnosis and repair of problems occurring in the printer and attached
options. Also included are detailed replacement procedures, parts lists, and wiring diagrams.
Manual Terms
Various terms are used throughout this manual to either provide additional information on a specific
topic or to warn of possible danger present during a procedure or action. Be aware of all symbols and
terms when they are used, and always read Note, Caution, and Warning statements.
WARNING: A warning indicates an operating or maintenance procedure, practice or condition
that, if not strictly observed, results in injury or loss of life.
CAUTION: A caution indicates an operating or maintenance procedure, practice or condition that,
if not strictly observed, results in damage to, or destruction of, equipment.
Replacement Note: A replacement note provides important information related to parts
replacement. When needed, replacement notes appear at the end of the disassembly procedure.
Note: A note indicates an operating or maintenance procedure, practice or condition that is
necessary to efficiently accomplish a task. A note can provide additional information related to a
specific subject or add a comment on the results achieved through a previous action.
