Service Parts Disassembly
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
4-8
Undocking the Printer
1. Check that all connections on the rear of the printer are disconnected.
2. Open the Access cover and disconnect the connector (CN 35) from the Main PWB.
3. Lift the printer off the Optional Tray 2 Base.
CN 35
