Xerox WorkCentre 3345 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
4-21
Top-Inner Cover (3335/3345)
Parts List 3.1 Frame (1 of 2)
1. Remove the Scanner Assembly (page 4-103).
2. Remove the Upper Middle Cover (page 4-23).
3. Remove the Lower Middle Cover (page 4-25).
4. Disconnect the Wireless Card connector (CN 33) and the USB connector (CN1).
CN 33
CN 1

Xerox WorkCentre 3345 Specifications

General

Brand	Xerox
Model	WorkCentre 3345
Category	All in One Printer
Language	English
