Xerox WorkCentre 3345 Service Manual

Image Quality
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
3-25
Image Specifications
The following table lists specifications for the printer.
Note: The printed image has 4.0 mm margins on all sides.
Characteristic Specification
Maximum Print Area 210.9 mm x 351.6 mm
Guaranteed Print Area 207.9 mm x 347.6 mm
Skew
Tray 1 (A4)
Tray 1 (LTR)
Bypass Tray (A4)
Bypass Tray (LTR)
180 mm ± 1.4 mm
200 mm ± 1.5 mm
180 mm ± 2.0 mm
200 mm ± 2.2 mm
Perpendicularity 140 mm ± 1.0 mm
Magnification Error
Horizontal
A4
LTR
180 mm ± 0.5 mm
200 mm ± 0.5 mm
Vertical
A4
LTR
280 mm ± 0.5 mm
260 mm ± 0.5 mm
Registration
Leading Edge ≤ ± 2.0 mm
Side Edge ≤ ± 2.5 mm
