Xerox WorkCentre 3345 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
4-5
Consumables
Refer to Xerox Supplies and Accessories for a list of consumables.
Toner Cartridge and Photoreceptor Drum Cartridge
1. Press the Front Button to open the Front Cover.
2. Hold the Toner Cartridge handle lift and pull the Toner Cartridge out of the printer.
3. Hold the Handle on the photoreceptor Drum Cartridge, lift up and pull the photoreceptor Drum
Cartridge out of the printer.
Photoreceptor Drum Cartridge
Toner Cartridge
Photoreceptor

Xerox WorkCentre 3345 Specifications

General

Brand	Xerox
Model	WorkCentre 3345
Category	All in One Printer
Language	English
