7-FRONT FORK COMPONENT
49
CHK
ADJ
NO. PART NO.
1 1194100-002000 ZT250－S right rearview mirror 1
3 1134100-032000 ZT250－R Right handle rocker (Machine) 1
4 1131200-017000 KD150－U hand guard 1
5 1250205-085000 GB70.1M6×70 (stainless steel) 1
6 1244100-042000 ZT250－R right handle bar rubber sleeve 1
8 1250205-031091 GB70.1M6×30(stainless steel) 2
PROCEDURE:
●Rearview mirror
Hold the mirror stem in one hand, remove the nut ④ with a 13# sleeve, and remove the small pad ③, the spring
② and the large pad ①. Remove the mirror from the front brake master pump.
●Right handlebar to put rubber sleeve,hand guard
Using 5# inner hexagon socket remove bolt⑸,take off the hand guard⑷,then take off the rubber sleeve⑹.
●Right handle switch
Hold the front disc brake main pump ⑵ with one hand, and remove the bolt ⑻ with a 5# inner hexagon socket
.Refer to the steps of removing the headlight assembly, first rotate the headlamp assembly forward and find the
line plug connector of the auxiliary switch ⑺ and remove it.
CAUTION:
●The motorcycle should be fixed after horizontal support.
●Periodically check that the fluid level of the brake fluid is between 3/4 of the observation window.
●Do not flush the cup directly with high pressure water.
●The small spacer of the rear view mirror anti-rotation limit slot needs to be aligned with the slot on the mirror
bar bolt.
●The right handlebar refers to the switch to replace the throttle line.
●The joint between the front disc brake main pump and the half cover should be aligned with the right hand to
match the triangle on the switch.
7 1184200-147000
ZT310－R second generation right sub－handle
switch (TFT)
1
1100300-044000
ZT125T front disc main pump assembly(without
rocker arm)
12
Fig.6 FRONT FORK
COMPONENT
Right hand component
