3.3.8. Inspection, cable harness
Location of cable harness, axes 1-4
The robot cable harness, axes 1-4, is located as shown in the figure below.
xx0600003434
IRB 6640 standard
A Lower arm
B SMB/BU unit
C Connectors at base
