4.3.7. Replacement of air nipple and hose (Foundry Prime)
3HAC026876-001 Revision: C242
© Copyright 2006-2008 ABB. All rights reserved.
4.3.7. Replacement of air nipple and hose (Foundry Prime)
Location
The illustration below shows the routing of the Foundry Prime air hose.
xx0500002176
Hose lengths
xx0700000449
Pos 1A Hose length 40 mm
Pos 1B Hose length 40 mm
Pos 1C Hose length 1520 mm
Pos 1D Hose length 1090 mm
Pos 1E Hose length 310 mm
Pos 1F Hose length 35 mm
