28 Mechanical installation
• The threaded holes in the top and bottom of the case are for cable clamps. The
holes are threaded for M4 bolts no longer than 11 mm (0.43 in).
• The D-type connectors on the front panel of the MicroFlex e150 are secured using
two hexagonal jack screws (sometimes known as “screwlocks”). If a jack screw is
removed accidentally or lost it must be replaced with a #4-40 UNC jack screw with
an external male threaded section no longer than 10 mm (0.4 in).
Required tools
• A small slot screwdriver(s) with a blade width of 3 mm or less for connector X1,
and 2 mm (1/10 in) or less for connectors X3 and X4.
• A drill, and M5 screws or bolts for mounting the MicroFlex e150.
• Wire stripper.
• For UL installations, use UL listed closed loop connectors that are of appropriate
size for the wire gauge being used.
• Connectors are to be installed using only the crimp tool specified by the
manufacturer of the connector.
Checking the delivery
Check that there are no signs of damage. Notify the shipper immediately if damaged
components are found.
If MicroFlex e150 is to be stored for several weeks before use, be sure that it is stored
in a location that conforms to the storage humidity and temperature specifications
shown in Ambient conditions on page 150.
Before attempting installation and operation, check the information on the type
designation label of the drive to verify that the drive is of the correct type. See section
Type designation label on page 25.
