Installation checklist 87
Installation checklist
This chapter contains a list for checking the mechanical and electrical installation of
the drive.
Checklist
Check the mechanical and electrical installation of the drive before start-up. Go
through the checklist together with another person.
WARNING! Only qualified electricians are allowed to carry out the work
described below. Follow the complete safety instructions of the drive. Ignoring
the safety instructions can cause injury or death. Open the main disconnector of the
drive and lock it to open position. Measure to ensure that the drive is not powered.
Check that …
The ambient operating conditions meet the specification in chapter Technical data.
There is an adequately sized protective earth (ground) conductor between the drive
and the metal mounting surface.
There is an adequately sized protective earth (ground) conductor between the motor
and the drive.
All protective earth (ground) conductors have been connected to the appropriate
terminals and the terminals have been tightened (pull conductors to check).
The supply voltage matches the nominal input voltage of the drive. Check the type
designation label.
The input power cable has been connected to appropriate terminals, the phase order
is correct, and the terminals have been tightened (pull conductors to check).
