ModOut On/Off AM
Pulse Pulse mo dulation is accepted from an external
source at the PULSE connector. In addition,
pulse mo dulation can also be internally generated.
The pulse is adjustable in standard swept signal
generators with 1.0

s resolution. Swept signal
generators can also pro duce a 27.778 kHz square
wave for use with HP/Agilent scalar network
analyzers. Swept signal generators with Option 002
generate a synthesized pulse that is adjustable with
25 ns resolution.
Additional information is available under \Mo dulation", or refer to
the type of mo dulation by name (AM, FM, Pulse).
See Also
\Mo dulation"
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
ModOut On/Off AM
Function Group
4
MOD
5
Menu Map
4
Description
This softkey (Option 002 only) lets you output the internally-
generated amplitude mo dulation waveforms to the rear panel
AM/FM OUTPUT connector. When scaled linearly at 100%/V, the
maximum output voltage is +1 V and the minimum output voltage is
0
1V.
Programming Codes
SCPI:
MODulation:OUTput:SOURce AM
MODulation:OUTput:STATeON
j
OFF
j
1
j
0
Analyzer:
NONE
See Also
4
MOD
5
, also see \AM" and \Mo dulation".
Operating and Programming Reference M-11
