Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 101
Manage the Switch via the Device Manager Web Interface Chapter 3
Upgrade the Switch
Firmware
You must have access to the Internet to download switch firmware from
http://www.rockwellautomation.com
to your computer or network drive.
Use the Device Manager Firmware Upgrade dialog box to update the switch with
the latest software changes (such as software patches) and features. From the
Device Manager Web interface, you can upgrade your switches one at a time.
To display this dialog box, choose Maintenance>Firmware Upgrade from the
Device Manager Web interface menu.
When the upgrade process completes, a success message appears, and the switch
automatically restarts. It might take a few minutes for the switch to restart with
the new firmware.
Forward Open Requests Rejected Due
to Format
The number of Forward Open requests directed to the switch that failed because the request is not in the proper
format.
Forward Open Requests Rejected For
Other
The number of Forward Open requests directed to the switch that failed for reasons such as incompatible
electronic keying.
Forward Close Requests Received The number of Forward Close requests received by the switch after a connection was successfully established
with the switch.
Forward Close Requests Rejected
Due to Format
The number of Forward Close requests directed to the switch that failed because the request is not in the proper
format.
Forward Close Requests Rejected For
Other
The number of Forward Close requests directed to the switch that failed for reasons such as incompatible
electronic keying.
Connection Time Outs The number of CIP connections that timed out due to inactivity.
Request Details Settings
State Description
Wait for the upgrade process to complete. Do not use or close
the browser session with the Device Manager Web interface
active. Do not access the Device Manager Web interface from
another browser session.
