50 Rockwell Automation Publication 1783-UM003G-EN-P - December 2012
Chapter 2 Switch Software Features
Alarms
The switch has two hardware alarm relay contacts on the switch front panel.
• Major alarm relay
When closed, the major alarm relay indicates a dual-mode power supply or
primary temperature alarm.
• Minor alarm relay
When closed, the minor alarm relay indicates these alarm states:
– Link fault
– Port not forwarding
– Port not operating
– Frame Check Sequence (FCS) bit error rate
Cryptographic IOS
Software (Optional)
The Stratix 8000 and Stratix 8300 cryptographic IOS (available as a separate
catalog number for downloading) provides network security by encrypting
administrator traffic during Telnet and SNMP sessions. The cryptographic IOS
supports all features of the standard IOS, as well as these protocols:
• Secure Shell (SSH) Protocol v2
• SNMPv3
• HTTPS
Cable Diagnostics
The Cable Diagnostics feature lets you run a test on each switch port to
determine the integrity of the cable connected to the gigabit ports or the RJ45
(copper) ports. This feature is not available for fiber ports.
The test determines the distance to the break from the switch for each cable with
a plus or minus error value individually listed.
Advanced Software
Features
More advanced software features are available, some of which are configured by
the global macro or Smartports for typical automation applications described in
this manual.
For information on how to configure features not available in the Device
Manager Web interface or the RSLogix 5000 software AOP, see the following
manuals:
• For more information on these features and how to modify them, see the
Cisco IE3000 Switch Software Configuration Manual, available from
http://www.Cisco.com
.
• For information on using the command-line interface for more detailed
configuring of these software features, see the Cisco IE3000 Switch
Command-Line Interface Manual, available from http://www.Cisco.com
.
