Appendix C Cables and Connectors
100BASE-FX Ports
The 100BASE-FX ports use the following:
• LC connectors, as shown in the following figure.
• 50/125- or 62.5/125-micron multimode fiber-optic cables
Figure 13 - Fiber-optic SFP Module LC Connector
SFP Module Ports
The switch uses SFP modules for fiber-optic uplink ports.
ATTENTION: Invisible laser radiation may be emitted from
disconnected fibers or connectors. Do not stare into beams or view
directly with optical instruments.
ATTENTION: Invisible laser radiation may be emitted from
disconnected fibers or connectors. Do not stare into beams or view
directly with optical instruments.
