Canon XF300 User Manual

Recording
100
3
Video Scopes
Options
Configuring the Vectorscope
The camcorder’s vectorscope function offers 2 modes. You can also
change the gain.
1 Open the [Vectorscope] submenu.
[J Other Functions] [WFM (LCD)] [Vectorscope]
2 Select the desired option and then press SET.
• If you do not need to change the gain, you do not need to perform
steps 3 and 4.
3 Open the vectorscope [Gain] submenu.
[J Other Functions] [WFM (LCD)] [Gain] (under [Vectorscope])
4 Select [1x] or [5x] and then press SET.
Options
Configuring the Edge Monitor
Using this video scope allows you to focus with more precision when the
camcorder is in full manual focus or manual focus mode. The edge
monitor features 2 modes.
1 Open the [Edge Monitor] submenu.
[J Other Functions] [WFM (LCD)] [Edge Monitor]
2 Select the desired option and then press SET.
[Line]: Sets the waveform monitor to line display mode.
[Line+Spot]: The waveform of the area in the red frame is displayed in red
on top of the [Line] mode waveform.
[Field]: Sets the waveform monitor to field display mode.
[RGB]: Functions like an RGB parade scope.
[YPbPr]: Functions like a YPbPr parade scope.
[J Other Functions]
[WFM (LCD)]
[Vectorscope]
[Normal]
[Spot]: The color signal of the area in the red frame is displayed in red on
top of the [Normal] mode waveform.
[Normal]: Displays the vectorscope.
[J Other Functions]
[WFM (LCD)]
[Edge Monitor]
[Type 1]
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
