Canon XF300 User Manual

107
Recording
3
Special Recording Modes
• The time code advances by the number of frames recorded. If the
running mode of the time code (0 84) is set to [Free Run] or the time
code is input from an external source (b only), the running mode
will switch to [Rec Run] during special recording mode. When special
recording mode is deactivated, the running mode will return to its
previous setting.
• b During special recording mode, the time code signal will not
be output from the TIME CODE terminal or HD/SD SDI terminal.
Slow & Fast Motion Mode
When you set [J Other Functions] [Frame Rate] to a progressive
frame rate (0 53), the camcorder can record with a frame rate (shooting
frame rate) that is different from the playback frame rate. Recording a clip
at a higher frame rate than the [Frame Rate] setting will result in a slow
motion effect during playback. Conversely, a lower frame rate will result in
a fast motion effect.
Sound is not recorded in this mode. This mode is not available if [J Other
Functions] [Bit Rate/Resolution] is set to [35 Mbps 1440x1080].
Configuring Slow & Fast Motion Mode
1 Open the [S&F Frame Rate] submenu.
[J Other Functions] [Slow & Fast Motion] [S&F Frame Rate]
2 Select the desired shooting frame rate and then press SET.
Available Shooting Frame Rates
* Available only when [J Other Functions] [Bit Rate/Resolution] is set to
[50 Mbps 1280x720] or [35 Mbps 1280x720].
Activating Slow & Fast Motion Mode and Recording
1 Open the [Special Rec] submenu.
[J Other Functions] [Special Rec]
2 Select [Slow & Fast Motion] and then press SET.
• [S&F STBY] appears at the top of the screen.
• The selected shooting frame rate appears on the right side of the
screen next to the [J Other Functions] [Frame Rate] setting (the
playback frame rate).
[J Other Functions]
[Slow & Fast Motion]
[S&F Frame Rate]
12 15 18 20 21 22 24 25 26 27
28 30 32* 34* 36* 40* 44* 48* 54* 60*
[J Other Functions]
[
Special Rec]
[Off]
Shooting frame rate
Playback frame rate
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
