Canon XF300 User Manual

41
Preparations
2
Preparing Recording Media
Inserting and Removing an SD Card
1 Turn off the camcorder ().
2 Open the SD card slot cover.
3 Insert the SD card straight, with the label facing the grip belt, all
the way into the SD card slot until it clicks ().
4 Close the SD card slot cover ().
• Do not force the cover closed if the SD card is not correctly inserted.
IMPORTANT
• Observe the following precautions while the SD card access indicator is
flashing. Failure to do so may result in permanent data loss.
- Do not disconnect the power source or turn off the camcorder.
- Do not remove the SD card.
• Turn off the camcorder before inserting or removing an SD card.
Inserting or removing the SD card with the camcorder on may result in
permanent data loss.
• SD cards have front and back sides that are not interchangeable.
Inserting an SD card facing the wrong direction can cause a
malfunction of the camcorder. Be sure to insert the SD card as
described in step 3.
NOTES
• To remove the SD card: Push the SD card once to release it. When
the SD card springs out, pull it all the way out.
• If you set the [J Other Functions] [Media Access LED] function to
[Off], the access indicators will not illuminate.
Initializing the Recording Media
The first time you use any recording media with this camcorder, initialize it
first. You can also initialize a recording media to permanently delete all the
data it contains.
When initializing an SD card, you can select quick initialization, which
clears the file allocation table but does not physically erase the stored
data, or complete initialization, which deletes all data completely.
1 Open the [Initialize Media] submenu.
[J Other Functions] [Initialize Media]
2 Select [CF A], [CF B] or [SD Card] and then press SET.



SD card access indicator
[J Other Functions]
[Initialize Media]
Operating modes:
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
