Canon XF300 User Manual

Introduction
12
1
About this Manual
Recording
3
Image Stabilizer
Image Stabilizer
Use the image stabilizer to compensate for camcorder shake in order to
achieve steadier shots. There are 3 methods of image stabilization; select
the method that best suits your needs.
1 Open the [Image Stabilizer] submenu.
[l Camera Setup] [Image Stabilizer]
2 Select the desired option and then press SET.
• The icon of the selected mode appears on the bottom of the screen.
Options
NOTES
• By default, assignable button 1 is set to [Standard] but you can also set
it for another assignable button instead. You can press the button to
activate standard IS.
• If you set an assignable button to [Dynamic IS] or [Powered IS]
(0 111), you can press the button to turn the assigned mode on or
off.
• If the degree of camcorder shake is too high, the image stabilizer may
not be able to fully compensate.
• When you are using [Dynamic] mode the edges of the picture may be
[l Camera Setup]
[Image Stabilizer]
[Standard]
Operating modes:
[Powered] Q: Powered IS is most effective when you are stationary and
zooming in on far subjects using high zoom ratios (the
more you approach the telephoto end). This mode is not
suitable for tilting and panning shots.
[Dynamic] P: Dynamic IS compensates for a higher degree of
camcorder shake, such as when shooting while walking,
and is more effective as the zoom approaches full wide
angle.
[Standard] O: Standard IS compensates for a lower degree of
camcorder shake, such as when shooting while remaining
stationary, and is suitable for shooting natural-looking
scenes.
[Off]: Use this setting when the camcorder is mounted on a
tripod.
Operating modes
indicates that a function is available in the
operating mode indicated and indicates that the
function is not available. For a detailed explanation,
refer to Turning the Camcorder On and Off (0 27).
When a procedure requires selecting an option,
the available options are listed within or after the
procedure. Brackets [ ] are used to refer to menu
options as they are displayed on screen.
The arrow is used to abbreviate menu selections. For
a detailed explanation on how to use the menus,
refer to Using the Menus (0 30). For a concise
summary of all available menu options and settings,
refer to the appendix Menu Options (0 169).
When a function requires the use of the menu,
the quick reference shows the submenus and,
when applicable, the default setting for the
menu item. The example illustration indicates
that you can find the function by selecting the
[l Camera Setup] menu and then the [Image
Stabilizer] menu item.
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
