Canon XF300 User Manual

Recording
98
3
Colors Bars/Audio Reference Signal
Col ors Ba rs/Aud io Refer ence S ignal
You can have the camcorder generate and record color bars and a 1 kHz
audio reference signal and output them from the HD/SD SDI terminal
(b only), HDMI OUT terminal, HD/SD COMPONENT OUT
terminal
1
, AV terminal, VIDEO 2 terminal
1
and W (headphone) terminal
2
.
1
Outputs color bars only.
2
Outputs audio reference signal only.
Recording Color Bars
You can choose between SMPTE standard-definition color bars ([Type 1])
and ARIB multi-format HDTV color bars ([Type 2]).
1 Open the color bars [Type] submenu.
[l Camera Setup] [Color Bars] [Type]
2 Select [Type 1] (SMPTE) or [Type 2] (ARIB) and then press SET.
3 Open the [Enable] submenu to activate the color bars.
[l Camera Setup] [Color Bars] [Enable]
4 Select [On] and then press SET.
• The selected color bars appear on the screen and will be recorded
when you press the START/STOP button.
• Turning the camcorder off or changing the operating mode to
mode will deactivate the color bars.
• Alternatively, you can set an assignable button to [Color Bars]
(0 113) to activate the color bars.
Recording an Audio Reference Signal
The camcorder can output a 1 kHz audio reference signal with the color
bars.
1 Open the [1 kHz Tone] submenu.
[m Audio Setup] [Audio Input] [1 kHz Tone]
2 Select the desired level and then press SET.
• Available levels are -12 dB, -18 dB and -20 dB.
• Select [Off] to turn off the signal.
• The signal is output at the selected level and will be recorded when
you press the START/STOP button.
Operating modes:
[l Camera Setup]
[Color Bars]
[Type]
[Type 1]
[l Camera Setup]
[
Color Bars]
[Enable]
[Off]
[m Audio Setup]
[Audio Input]
[1 kHz Tone]
[Off]
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
