Canon XF300 User Manual

External Connections
148
6
Connecting to an External Monitor
b Using the HD/SD SDI Terminal
The digital signal output from the HD/SD SDI terminal includes the video
signal, audio signal and time code signal. If necessary, perform the
following procedure to change the output to HD or SD. Turning the output
off will conserve the camcorder’s power.
1 Open the [SDI Output] submenu.
[N Video Setup] [SDI Output]
2 Select the desired option and then press SET.
• If you selected [HD], no more settings need to be made. If you
selected [SD], you can select the SD output method (0 146).
NOTES
• If necessary, you can superimpose the onscreen displays on the video
displayed on the external monitor (0 149).
Using the HDMI OUT Terminal
The HDMI
TM
OUT terminal also offers a digital connection and outputs
both a video and audio signal. The output signal will automatically switch
to HD or SD depending on the capability of the external monitor.
NOTES
• Correct operation cannot be guaranteed when connecting the
camcorder to DVI monitors.
• Video may not be output correctly depending on the monitor. In such
case, use another terminal.
• If necessary, you can superimpose the onscreen displays on the video
displayed on the external monitor (0 149).
• You can select the SD output method (0 146).
Using the HD/SD COMPONENT OUT Terminal
The HD/SD COMPONENT OUT terminal outputs an analog HD or SD
video signal. If necessary, perform the following procedure to change the
output to HD or SD.
1 Open the [Component Output] submenu.
[N Video Setup] [Component Output]
2 Select the desired option and then press SET.
• If you selected [HD], no more settings need to be made. If you
selected [SD], you can select the SD output method (0 146).
[N Video Setup]
[SDI Output]
[Off]
[N Video Setup]
[Component Output]
[HD]
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
