Canon XF300 User Manual

Customization
114
4
Assignable Buttons
Using an Assignable Button
After you assign a function to one of the buttons, press the button to
activate the function. For some functions, an options menu may appear.
In such case, select the desired option and then press SET.
Assignable Functions
Functions can be set separately in mode and mode. Refer to the following table for assignable
functions and available modes.
* Function can be used only by assigning it to a button.
Function name Description 0
[Standard IS] Turns standard IS on/off. N – 62
[Dynamic IS] Turns Dynamic IS on/off. N – 62
[Powered IS] Turns Powered IS on/off. N – 62
[Focus Limit] Turns the focus limit on/off. N – 61
[Face AF] Turns auto focusing on faces on/off. N – 60
[Select Face]* Selects the main subject when using [Face AF] to focus on subjects’ faces. N – 60
[Backlight] Turns the backlight light metering option on/off. N – 71
[Spotlight] Turns the spotlight light metering option on/off. N – 71
[Tele-converter] Turns the digital tele-converter on/off. N – 170
[Peaking] Turns peaking on/off. N – 57
[Zebra] Turns zebra patterns on/off. N – 82
[WFM (LCD)]
Activates video scopes in the following sequence:
Waveform monitor J Vectorscope J Edge monitor J Off
N N 99
[Magnification] Turns magnification on/off. N – 57
[Color Bars] Turns color bars on/off. N – 98
[Markers] Turns onscreen markers on/off. N – 81
[LCD Setup] Opens the [LCD Setup] submenu. N N 34
[LCD/VF B&W] Turns the B&W mode of the LCD and viewfinder on/off. N N 35
[Onscreen Display] Displays the onscreen icons and text on an external monitor (for both SD and HD output). N N 149
[Shot Mark 1] Adds an c mark to the clip. N N 102
[Shot Mark 2]* Adds an d mark to the clip. N N 102
[Add e Mark] Adds an e mark to the clip. N N 137
[Add Z Mark] Adds a Z mark to the clip. N N 137
[Time Code] Displays the [Time Code] submenu. N – 84
[Time Code Hold]* Puts the time code display on hold or resumes it. N N 84
[Audio Output CH] Switches the audio output channel. N N 151
[Audio Level] Turns the audio level meter on/off. N N 95
[Wireless Controller] Turns the wireless controller on/off. N N 37
[Photo]* Records a photo. N N 161
[Rec Review] Plays back the last clip recorded. N – 103
[Delete Last Clip] Deletes the last clip recorded. N – 140
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
