Canon XF300 User Manual

149
External Connections
6
Connecting to an External Monitor
NOTES
• If necessary, you can superimpose the onscreen displays on the video
displayed on the external monitor (0 149).
Using the AV or VIDEO 2 Terminal
When you output video from the AV terminal or VIDEO 2 terminal, the
video signal is converted to an analog SD composite video signal. While
the VIDEO 2 terminal outputs only video, the AV terminal also outputs
audio. You can select the SD output method (0 146).
NOTES
• If necessary, you can superimpose the onscreen displays on the video
displayed on the external monitor (0 149).
• When you play back a clip on a monitor with a 4:3 aspect ratio, the
monitor will switch automatically to widescreen mode if it is compatible
with the Video ID-1 system.
Superimposing Onscreen Displays to Appear on an
External Monitor
You can choose to superimpose onscreen displays on the video output
from the HD/SD SDI terminal (b only), HDMI OUT terminal, HD/SD
COMPONENT OUT terminal, AV terminal or VIDEO 2 terminal. Doing so
will display the onscreen displays on an external monitor. You must set
this function separately for HD and SD output. This setting will not affect
your recordings.
1 Open the [HD Onscreen Disp.] or [SD Onscreen Disp.] submenu.
[N Video Setup] [HD Onscreen Disp.] or [SD Onscreen Disp.]
2 Select [On] and then press SET.
• G appears on the right side of the screen (when [M LCD/VF
Setup] [Custom Display] [Output Display] is set to [On]).
NOTES
• Onscreen displays will not appear on an external monitor for SD output
if [N Video Setup] [SD Output] is set to [Side Crop].
[N Video Setup]
[HD Onscreen Disp.]
[SD Onscreen Disp.]
[Off]
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
