91
Recording
3
Recording Audio
Recording Audio
The camcorder features two-channel linear PCM audio recording and
playback with a sampling frequency of 48 kHz. You can record audio
using the built-in microphone, optional external microphone (XLR
terminal) or line input (XLR terminal). You can select the audio input
independently for channel 1 and channel 2.
Using the Built-in Microphone
After you activate the built-in microphone, you can configure the low-cut
filter and sensitivity, and activate the attenuator.
Set the AUDIO IN switch of the desired channel to INT.
Configuring the Low-Cut Filter
1 Open the [Int. Mic Low Cut] submenu.
[m Audio Setup] [Audio Input] [Int. Mic Low Cut]
2 Select the desired option and then press SET.
Options
Operating modes:
[m Audio Setup]
[Audio Input]
[Int. Mic Low Cut]
[Off]
[Off]: For recording audio under usual conditions.
[LC1]: For recording mainly peoples voices.
[LC2]: For reducing the background sound of wind when recording
outdoors in windy surroundings (for example, on a beach or close to
buildings). Note that when you use this setting some low-frequency
sounds may be suppressed along with the sound of wind.
COPY
Downloaded From VideoCamera-Manual.com Manuals

Table of Contents

Other manuals for Canon XF300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon XF300 and is the answer not in the manual?

Canon XF300 Specifications

General IconGeneral
Filter size82 mm
Digital zoom1.5 x
Optical zoom18 x
Image stabilizerYes
Focal length range4.1 - 73.8 mm
Focal length (35mm film equivalent)29.3 - 527.4 mm
Sensor typeCMOS
Total megapixels2.37 MP
Optical sensor size1/3 \
Video out1
Flash memory32768 MB
Aperture range (F-F)1.6 - 22
Horizontal resolution1000 lines
Power consumption (typical)9 W
Viewfinder resolution1550000 pixels
Viewfinder screen size0.57 \
Display diagonal4 \
ISO sensitivityAuto
Normal focusing range0.02 - 1 m
Maximum frame rate50 fps
Maximum video resolution1920 x 1080 pixels
Image formats supportedJPG
Audio formats supportedMP3
Camera shutter speed1/18 - 1/2000 s
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Compatible memory cardsSD, SDHC
Product colorBlack
Video recording time1.2 h
Operating temperature (T-T)-5 - 45 °C
Weight and Dimensions IconWeight and Dimensions
Depth180 mm
Width394 mm
Height192 mm
Weight2700 g
