Canon XF300 User Manual

Preparations
30
2
Using the Menus
Using the Menus
In mode, many of the camcorder’s functions can be adjusted from
the menu for general settings, which opens after pressing the MENU
button. In mode, press the MENU button to open the menu for
general settings or SET to open the clip menu for clip operations. For
details about the available menu options and settings, refer to Menu
Options (0 169).
Selecting an Option from the Menu
The following is a step-by-step explanation of how to select an option
from the menu. In the procedures throughout the rest of this manual,
opening and closing the menu is assumed and not included in the
procedure.
1 Press the MENU button.
• The menu opens with the orange selection frame indicating the menu
item that was selected the previous time the menu was closed
(unless the camcorder was turned off).
2 Push the joystick up/down or turn the SELECT dial to select the
desired submenu.
3 Push the joystick right or press SET.
• The orange selection frame will appear on a menu item in the
submenu.
• Press the CANCEL button, push the joystick left, or select [a] to
return to the previous submenu.
Operating modes:
MENU button
Press to open the menu and then
press again to close the menu after
adjusting desired settings.
Joystick/SET button
Push the joystick to move the orange selection frame in the
menu. Then, press the joystick itself (SET button) or the SET
button next to the SELECT dial to select the menu item
indicated by the orange selection frame.
SELECT dial
Turn the dial to move the orange selection
frame up or down in the menu.
CANCEL button
Press to return to the previous menu or to
stop some operations that are in progress.
CANCEL button
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
