Preparations
38
2
Preparing the Camcorder
NOTES
You can also activate the wireless controller by setting an assignable
button to [Wireless Controller] (0 113).
Using the Wireless Controller to Operate the Camcorder
When using the wireless controller, point it at the camcorder’s remote
sensor. When the wireless controller's buttons are operated, the
camcorder's tally lamps will illuminate.
NOTES
When you use the START/STOP button or ZOOM buttons on the
wireless controller, you must press the record enable button
simultaneously with the desired button.
When the camcorder cannot be operated with the wireless controller,
or when it can only be operated at very close range, replace the battery.
The wireless controller may not work properly when the remote sensor
is located under strong light sources or direct sunlight.
Using a Tripod
You can mount the camcorder on a tripod but do not use tripods with
mounting screws longer than 5.5 mm (0.2 in.) as this may cause damage
to the camcorder.
Using a Tripod with 3/8" Mounting Screws
To use a tripod with 3/8" mounting screws, first attach the optional TB-1
Tripod Adapter Base to the camcorder and then attach the tripod to the
adapter base.
1 Remove the tripod base from the camcorder.
Remove the 4 screws and then remove the base.
2 Attach the optional TB-1 Tripod Adapter Base.
Firmly screw in the 4 screws.
3 Attach the tripod.
Firmly screw in the tripod screw.
If a tripod has both a 1/4" screw and 3/8" mounting screw, firmly
screw in both.
COPY
Downloaded From VideoCamera-Manual.com Manuals

Table of Contents

Other manuals for Canon XF300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon XF300 and is the answer not in the manual?

Canon XF300 Specifications

General IconGeneral
Filter size82 mm
Digital zoom1.5 x
Optical zoom18 x
Image stabilizerYes
Focal length range4.1 - 73.8 mm
Focal length (35mm film equivalent)29.3 - 527.4 mm
Sensor typeCMOS
Total megapixels2.37 MP
Optical sensor size1/3 \
Video out1
Flash memory32768 MB
Aperture range (F-F)1.6 - 22
Horizontal resolution1000 lines
Power consumption (typical)9 W
Viewfinder resolution1550000 pixels
Viewfinder screen size0.57 \
Display diagonal4 \
ISO sensitivityAuto
Normal focusing range0.02 - 1 m
Maximum frame rate50 fps
Maximum video resolution1920 x 1080 pixels
Image formats supportedJPG
Audio formats supportedMP3
Camera shutter speed1/18 - 1/2000 s
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Compatible memory cardsSD, SDHC
Product colorBlack
Video recording time1.2 h
Operating temperature (T-T)-5 - 45 °C
Weight and Dimensions IconWeight and Dimensions
Depth180 mm
Width394 mm
Height192 mm
Weight2700 g
