Preparations
42
2
Preparing Recording Media
To initialize a CF card
3 Select [OK] and then press SET.
4 When the confirmation message appears, press SET.
The CF card is initialized and all the data it contains is erased.
To initialize an SD card
3 Select [Complete] (complete initialization) or [Quick] (quick
initialization) and then press SET.
4 Select [OK] and then press SET.
If you are using the [Complete] initialization option, press SET twice
to cancel the operation while it is in progress. You can use the SD
card but all data will be erased.
5 When the confirmation message appears, press SET.
The SD card is initialized and all the data it contains is erased.
IMPORTANT
Initializing the recording media will permanently erase all data, including
clips with an e mark, protected photos, and custom picture
information. Lost data cannot be recovered. Make sure you save
important recordings in advance.
Depending on the SD card, the complete initialization may take up to a
few minutes.
NOTES
While recording on a CF card, you can initialize another CF card in the
other CF card slot.
Switching Between the CF Card Slots
The camcorder features two CF card slots, CFj (CF card slot A) and
CFl (CF card slot B). If both slots contain a CF card, you can switch
between them as necessary. In addition, if the CF card you are using
becomes full while recording, the recording will continue uninterrupted on
the other CF card (relay recording). Relay recording is available from CF
card slot A to CF card slot B, and vice versa.
Press the SLOT SELECT button.
The access indicator of the selected CF card slot will illuminate in
green.
Operating modes:
COPY
Downloaded From VideoCamera-Manual.com Manuals

Table of Contents

Other manuals for Canon XF300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon XF300 and is the answer not in the manual?

Canon XF300 Specifications

General IconGeneral
Filter size82 mm
Digital zoom1.5 x
Optical zoom18 x
Image stabilizerYes
Focal length range4.1 - 73.8 mm
Focal length (35mm film equivalent)29.3 - 527.4 mm
Sensor typeCMOS
Total megapixels2.37 MP
Optical sensor size1/3 \
Video out1
Flash memory32768 MB
Aperture range (F-F)1.6 - 22
Horizontal resolution1000 lines
Power consumption (typical)9 W
Viewfinder resolution1550000 pixels
Viewfinder screen size0.57 \
Display diagonal4 \
ISO sensitivityAuto
Normal focusing range0.02 - 1 m
Maximum frame rate50 fps
Maximum video resolution1920 x 1080 pixels
Image formats supportedJPG
Audio formats supportedMP3
Camera shutter speed1/18 - 1/2000 s
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Compatible memory cardsSD, SDHC
Product colorBlack
Video recording time1.2 h
Operating temperature (T-T)-5 - 45 °C
Weight and Dimensions IconWeight and Dimensions
Depth180 mm
Width394 mm
Height192 mm
Weight2700 g
