Canon XF300 User Manual

Recording
108
3
Special Recording Modes
3 Press the START/STOP button to begin recording.
• The camcorder automatically records at the set frame rate.
• The tally lamps illuminate.
• [S&F STBY] changes to [N S&F REC] while recording.
4 Press the START/STOP button again to stop recording.
• The camcorder records the clip.
• The tally lamps go out and [S&F STBY] appears at the top of the
screen.
NOTES
• You can use only one special recording mode at a time. In addition,
slow & fast motion mode cannot be used with double slot recording.
• While recording, you cannot change the shooting frame rate.
• For lower shooting frame rates, it may take approximately 1 second to
stop recording.
• Slow & fast motion mode will be deactivated if the special recording
mode is changed or turned off. It will be deactivated also if you change
the video configuration.
• The time code advances while video is recorded. If the running mode of
the time code (0 84) is set to [Free Run] or the time code is input from
an external source (b only), the running mode will switch to [Rec
Run] during special recording mode. When special recording mode is
deactivated, the running mode will return to its previous setting.
• b During special recording mode, the time code signal will not
be output from the TIME CODE terminal or HD/SD SDI terminal.
• When the bit rate is set to 50 Mbps (0 53) during slow motion
recording, relay recording is not available.
Pre-recording Mode
When pre-recording mode is activated, the camcorder starts recording
continuously into a temporary memory of approximately 3 seconds so
when you press the START/STOP button, the clip will contain also
approximately 3 seconds of video and audio recorded before you
pressed the button.
1 Open the [Special Rec] submenu.
[J Other Functions] [Special Rec]
2 Select [Pre Rec] and then press SET.
• [PRE REC STBY] appears at the top of the screen.
3 Press the START/STOP button to begin recording.
• The tally lamps illuminate.
• [PRE REC STBY] changes to [N PRE REC] while recording.
[J Other Functions]
[
Special Rec]
[Off]
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
