Canon XF300 User Manual

Additional Information
186
8
Troubleshooting
Playback
Cannot delete a clip.
- You cannot delete clips with an e mark. Remove the e mark (0 138) to delete the clip.
Deleting clips takes longer than usual.
- When the CF card contains a large number of clips, some operations may take longer than usual. Save your clips
(0 152) and initialize the CF card (0 41).
Cannot delete a photo.
- The photo is protected. Remove the protection (0 117).
- The LOCK switch on the SD card is set to prevent accidental erasure. Change the position of the LOCK switch.
Cannot copy clips.
- There is not enough available space on the CF card being copied to or the CF card already contains the maximum
number of clips (999 clips). Delete some clips (0 140) to free some space or replace the CF card.
Indicators and Onscreen Displays
U lights up in red.
- Battery pack is exhausted. Replace or charge the battery pack.
V appears on the screen.
- The camcorder cannot communicate with the battery pack attached so the remaining battery time cannot be displayed.
The tally lamps do not illuminate.
- Set [Other Functions] [Tally Lamp] [Front] or [Rear] to [On].
The tally lamps flash quickly. (4 flashes per second)
- The battery pack is exhausted. Replace or charge the battery pack.
- There is not enough available space on the CF card. Delete some clips (0 140) to free some space or replace the CF
card.
- A system error has occurred. Turn off the camcorder and back on again. If this does not solve the problem, consult a
Canon Service Center.
The tally lamps flash slowly. (1 flash per second)
- The combined available space on both CF cards is low. Replace the CF card that is not being recorded onto.
O appears in red on the screen.
- The focus mode ring is not correctly set. Turn the ring to either AF/MF or FULL MF until the PUSH button locks (0 54) .
b appears in red on the screen.
- An SD card error occurred. Turn off the camcorder. Remove and reinsert the SD card. Initialize the SD card if the display
does not change back to normal.
- The SD card is full. Replace the SD card or delete some photos (0 164) to free some space on the SD card.
Even after stopping recording, the CFj/CFl access indicator stays illuminated in red.
- The clip is being recorded. This is not a malfunction.
Picture and Sound
Screen displays turn on and off repeatedly.
- The battery pack is exhausted. Replace or charge the battery pack.
- Remove the battery pack and reattach it correctly.
Abnormal characters appear on the screen and the camcorder does not operate properly.
- Disconnect the power source and reconnect it after a short time. If the problem still persists, perform one of the
following actions.
• Disconnect the power source and press the RESET button. This resets all the camcorder’s settings to default values
except for custom picture settings and the hour meter.
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
