Canon XF300 User Manual

39
Preparations
2
Preparing Recording Media
Preparin g Recording M edia
The camcorder records clips to CompactFlash (CF) cards and
photos* to SD and SDHC memory cards. The camcorder is
equipped with two CF card slots. Initialize recording media (0 41) when
you use them with this camcorder for the first time.
* The camcorder can record custom picture settings and camera settings on to an
SD card. To record a user memo with a clip, use the supplied Canon XF Utility
software to a create user memo file and save it to the SD card. The camcorder
can read the file and embed it in the clip.
Compatible CF cards
You can use UDMA-compatible* Type I CF cards with a capacity of at
least 512 MB with the camcorder. For more details, visit your local Canon
Web site.
* The Ultra Direct Memory Access (UDMA) specification allows data to be
transferred between the CF card and device at high transfer speeds (measured in
MBps). Depending on the CF card, you may not be able to record even when
using a UDMA-comptaible CF card.
NOTES
• Proper operation cannot be guaranteed for all CF cards.
Inserting a CF Card
You can insert a CF card into CF card slot A or slot B. If you have two CF
cards, you can use both slots.
1 Slide the CF card slot cover switch in the direction of the E
mark ().
• The CF card slot cover will open upward (slot A) or downward
(slot B).
2 Insert the CF card straight, with the label facing up, all the way
into the slot ().
3 Close the CF card slot cover ().
• Do not force the cover closed if the CF card is not correctly inserted.



COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
