Canon XF300 User Manual

145
External Connections
6
Video Output Configuration
6
External Connections
External Connections
Video Ou tput Configur ation
The video signal output from the HD/SD SDI (b only), HDMI OUT
and HD/SD COMPONENT OUT terminals depends on the clip’s video
configuration, the capability of the external monitor (for video output from
the HDMI OUT terminal) and on various menu settings. Video output from
the AV or VIDEO 2 terminal will always be in 480/60i standard.
Video Output Configuration by Terminal
Refer to the following table for the video output configuration from each
terminal. If necessary, you can superimpose the onscreen displays on the
video displayed on the external monitor (0 149).
Operating modes:
V
ideo Output Configuration by Terminal
1
Set [N Video Setup] [SDI Output] to [HD], [SD] or [Off].
2
When you set [M LCD/VF Setup] [HD Output] (under [Zebra]) to [On], you can display zebra patterns on an external monitor. In
such case, output from the HD/SD SDI terminal (b only) and HD/SD COMPONENT OUT terminal will be in HD, regardless of
their setting.
3
Video output will automatically switch to HD or SD, depending on the capability of the external monitor.
4
Set [N Video Setup] [Component Output] to [HD] or [SD].
5
When output from the HDMI OUT terminal is SD (480/60P), the output of the HD/SD SDI terminal will also be 480/60P.
Terminal J
HD/SD SDI
1, 2
(b only)
HDMI OUT
2, 3
HD/SD COMPONENT
OUT
2, 4
AV or
VIDEO 2
Recording frame
size / Frame rate L
HD
output
SD
output
HD
output
SD
output
HD
output
SD
output
SD
output
1080/60i
1080/60i 480/60i
5
1080/60i 480/60P 1080/60i 480/60i 480/60i
1080/30P
1080/24P
1080/slow or
fast motion
720/60P
720/60P 480/60i
5
720/60P 480/60P 720/60P 480/60i 480/60i
720/30P
720/24P
720/slow or
fast motion
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
