Recording
46
3
Recording Video
Recording
1 Hold down the button on the d switch and move it to
CAMERA (
0 27).
• The camcorder turns on in mode and enters record pause
mode.
• The access indicator for the CF card slot selected for recording
illuminates in red and then changes to green.
2 Press the START/STOP button to begin recording.
• Recording starts. The front and rear tally lamps illuminate and the
recording indicator [NREC] appears on the screen.
• You can use the START/STOP button on the side grip, handle or
below the iris ring.
• When you use the wireless controller, press the START/STOP button
and the record enable button simultaneously.
3 Press the START/STOP button to pause the recording.
• The clip* is recorded to the CF card and the camcorder enters record
pause mode. The tally lamps will also go out.
* “Clip” refers to one movie unit from the point you press the START/STOP button
to start recording until you press again to pause the recording. You can also
include custom picture settings (0 115) and metadata (0 97) with the clip.
IMPORTANT
• Observe the following precautions while the CFj or CFl access
indicator is illuminated in red. Failure to do so may result in permanent
data loss.
- Do not open the CF card slot cover of the CF card slot being
accessed and remove the CF card.
- Do not disconnect the power source or turn off the camcorder.
• Be sure to save your recordings regularly (0 152), especially after
making important recordings. Canon shall not be liable for any loss or
corruption of data.
NOTES
• The START/STOP button on the handle has a lock lever to prevent
accidental operation. Set the lock lever to R in cases such as when
you do not want a recording inadvertently paused or do not plan to use
the START/STOP button. Return the lever to its previous position to
enable use of the START/STOP button again.
COPY
Downloaded From VideoCamera-Manual.com Manuals

Canon XF300 Specifications

General

Filter size	82 mm
Digital zoom	1.5 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	4.1 - 73.8 mm
Focal length (35mm film equivalent)	29.3 - 527.4 mm
Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Video out	1
Flash memory	32768 MB
Aperture range (F-F)	1.6 - 22
Horizontal resolution	1000 lines
Power consumption (typical)	9 W
Viewfinder resolution	1550000 pixels
Viewfinder screen size	0.57 \
Display diagonal	4 \
ISO sensitivity	Auto
Normal focusing range	0.02 - 1 m
Maximum frame rate	50 fps
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Audio formats supported	MP3
Camera shutter speed	1/18 - 1/2000 s
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Compatible memory cards	SD, SDHC
Product color	Black
Video recording time	1.2 h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	180 mm
Width	394 mm
Height	192 mm
Weight	2700 g
