1-16
Cisco ASA Series CLI Configuration Guide
Chapter 1 Configuring the ASA CX Module
Monitoring the ASA CX Module
--- --------------------------------- ------------ ------------ ---------------
0 5475.d05b.1100 to 5475.d05b.110b 1.0 2.0(7)0 100.7(6)78
1 5475.d05b.2450 to 5475.d05b.245b 1.0 2.0(13)0 0.6.1
Mod SSM Application Name Status SSM Application Version
--- ------------------------------ ---------------- --------------------------
1 ASA CX Security Module Up 0.6.1
Mod Status Data Plane Status Compatibility
--- ------------------ --------------------- -------------
0 Up Sys Not Applicable
1 Up Up
Showing Module Statistics
To show module statistics, enter the following command:
Examples
The following is sample output from the show service-policy command showing the ASA CX policy
and the current statistics as well as the module status when the authentication proxy is disabled:
hostname# show service-policy cxsc
Global policy:
Service-policy: global_policy
Class-map: bypass
CXSC: card status Up, mode fail-open, auth-proxy disabled
packet input 2626422041, packet output 2626877967, drop 0, reset-drop 0, proxied 0
The following is sample output from the show service-policy command showing the ASA CX policy
and the current statistics as well as the module status when the authentication proxy is enabled; in this
case, the proxied counters also increment:
hostname# show service-policy cxsc
Global policy:
Service-policy: pmap
Class-map: class-default
Default Queueing Set connection policy: random-sequence-number disable
drop 0
CXSC: card status Up, mode fail-open, auth-proxy enabled
packet input 7724, packet output 7701, drop 0, reset-drop 0, proxied 10
Command Purpose
show service-policy cxsc
Displays the ASA CX statistics and status per service policy.
