Coastcom D/I Mux III System User Manual

Chapter 3. Installation
86
Table 3-8. LIU DIP Switch (SW2) Selections
P/N 30309-104A and 30309-114A
SW2
Switch
Segment
Designation Selection Description
1 B8ZS Open B8ZS line coding
Closed Transparent line coding
2 B7 Open B7 line coding
Closed Transparent line coding
3 ESF Open ESF framing
Closed SF framing
4* TIM Closed Loop timing
Channel Bank, Dual Channel
Bank, and ALPS modes
Open Local timing
4* TIM Closed Network timing from T1-2
Drop/Insert mode Open Network timing from T1-1
5 DCB Open Dual Channel Bank mode
Closed No effect
6 CHN Open Channel Bank mode
Closed Drop/ Insert mode
7 YEL Open Pass through yellow alarm
Closed Block yellow alarm
8 ALPS Open ALPS mode
Closed No effect
* Switch SW2-4 will perform a different function depending on the multiplexer mode selection as
determined by switch segments 5, 6, and 7.
The D/I Mux III has Non-Volatile Random Access Memory (NVRAM) allowing the LIUs to
be software-configured. System configuration on a power-up can be accomplished with
the System Configuration (SC) command. Refer to Chapter 4. Configuration and
Operation for more information on the SC command.
T1 Interfaces
The two types of T1 interface that can be used in a D/I Mux III system include the Dual DSX-1
Interface, which transmits and receives a basic DSX-1 signal, and the Dual CSU Interface which
allows the D/I Mux III to perform the functions of a Channel Service Unit (CSU).
Dual Standard or Enhanced DSX-1 Interfaces (No CSU Function)
