Chapter 4. Configuration and Operation
148
To “Quit” at the Line Card Slot Number prompt, simply press [Enter]. Figure 4-57 depicts the prompts
that appear when quitting the line card assignments. The updated line card map and DS0 assignment
map are shown, as a review of the information that has just been entered. In the DS0 assignment map,
the x designates a through DS0. (Make sure the ‘x’ is on the data line. A misplaced ‘x’ may interfere
with the through DS0.)
If more editing is desired, select Yes at the Edit More prompt. This allows corrections to be made as
necessary, as well as editing the opposite T1 direction, and clearing maps. Once editing tasks are
completed, press No. The map can then be reviewed, and work can be saved with a Yes response to
the Apply Changes prompt.
10:33:38----------------- [ Linecard Map 3 : T1-1 ] -----------------08/18/96
DS0:
SLOT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
-----------------------------------------------------------------------------
1A TR
2 TR
-----------------------------------------------------------------------------
** Press Enter to Continue **
10:33:46---------- [ WORKING DS0 Assignment Map 4 : T1-1 ] ----------08/18/96
DS0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
-----------------------------------------------------------------------------
Voice TR
Data TR x x x x x x x x x x x x x x x x x x x x x x
-----------------------------------------------------------------------------
Slot 1 2
Edit More
Y) Yes
N) No
[Y/N] N
Review Map
Y) Yes
N) No
[Y/N] N
Apply Changes
Y) Yes
N) No
[Y/N] Y
Figure 4-57. Editing Line Card Assignments
SN - Setting the Working Map
Use the SN command to Set the New working map. Figure 4-58 depicts the screen prompts for the
current and new working map numbers.
