Coastcom D/I Mux III System User Manual

Chapter 4. Configuration and Operation
149
] SN
Current Working Map: 1
New Working Map Number
(1..7) 1
Are You Sure?
Y) Yes
N) No
[Y/N]
Figure 4-58. Setting the Working Map
SO - Setting the Communications Configuration
Applicable only to the CCU portion of the system, and not supported by the MCU, the SO command is
used to display and set the communications configuration (Figure 4-59). When operating with the MCU,
and in the SNMP mode, values displayed in the applicable communications modes should not be
changed. For detailed information on communications configuration, refer to Appendix J. Set Report
Options.
] SO
Current Mode
TERM - DIALOUT ALARM REPORTING
Communication Configuration
C) COMM mode
D) Display Modem/Port expander Config.
M) Change Modem Config.
P) Change Port Expander Config.
Q) Quit
] Q
Figure 4-59. Displaying and Setting the Communications Configuration
SP - Setting System Operation Parameters
Use the SP command to Set the system operation Parameters. System parameters include the
following.
Use of installed line cards to check map display - This allows a check on the bandwidth, based on the
line cards in the shelf.
Shelf size - Number of slots
System Identification Number - This should remain at factory default setting of “0”.
