Coastcom D/I Mux III System User Manual

Chapter 5. Diagnostics
197
OD - Operate Diagnostics
Enter OD to access the Operate Diagnostics screen as depicted below. The example in Figure 5-25 is of
a Dual CSU Interface (Integrated CSU) card in channel bank mode.
] OD
17:19:37----------- [ Operate Diagnostics ] ----------02/01/96
CSU Loopback
Normal
T1-1
----
0) Clear Loopback
2) Set PAYLOAD Loopback
4) Set LINE Loopback
6) Send REM Loop-up
8) Send REM Loop-down
Shelf Controls
--------------
C) Bypass E) Reset Common/Line Cards
D) Unbypass F) Unloop Line Cards
G) Shelf Restart O) Acknowledge ACO
H) Display Alarms
Q) Quit
** Warning: Ensure that a network clock source is
provided for the T1 port under test.
Are You Sure?
Y) Yes
N) No
[Y/N]
Figure 5-25. Channel Bank Mode Operate Diagnostics Screen
