D/I Mux III User’s Manual Appendix D. Preconfigured Maps
Appendix D. PRECONFIGURED MAPS
Eight pre-configured maps are available on the Strobe unit, and are described in this appendix. Select a
map to match the desired application from the maps described in this appendix. If a map is required
which differs from those supplied here, use the Set/edit Map matrix (SM) command to configure a
custom map.
Use the Lower Strobe unit's option switches for map selection (see Figure 3-18), if software configuration
is not available. If a control terminal is available for system software configuration, activate the map by
selecting the Strobe card option switches in the Set shelf Configuration (SC) screen.
When given the choice of either a Nonvolatile Random Access Memory (NVRAM) or Strobe card option
shelf configuration, select the Strobe option by typing SC, then select O for Strobe Card Option
Switches, as depicted in Figure D-1.
SC
Enter Shelf Configuration Setting after Power Cycle
N) NVRAM
O) Strobe Card Option Switches
[N] O
Figure D-1. Strobe Option Switch Selection Screen
Review the Set/Edit Shelf Configuration section in Chapter 4. Configuration and Operation for details on
menu selections available with the SC command. Following selection of either NVRAM or Option switch
configuration, the next selections to be made are Mode of Operation, Shelf Timing, Frame Mode, Zero
Suppression Mode, T1 REM Alarm Output and, finally, Apply Changes (save settings).
