Coastcom D/I Mux III System User Manual

Chapter 4. Configuration and Operation
105
Obtaining System Access
The following procedure begins system configuration. After completing proper installation procedures,
and applying power to the D/I Mux III shelf, turn on the control terminal to commence system access.
The system will power up and, after a period of approximately 45 seconds, the password prompt
appears. At initial startup, it is not necessary to enter a password. Press [Enter]. To access the Main
Menu with a Common Control Unit (CCU), the screen in Figure 4-2 will appear. Type ? and press
[Enter].
Coastcom
1141 Harbor Bay Parkway
Alameda, CA 94502
18:19:13 11/01/95
Access Level is: 1
Alarm Reporting is : NO REPORTING
Type ? for Help
]?
08:42:57--------------------------[ Menu ]--------------------------11/28/95
ALARMS SYSTEM PARAMETERS
DA Display DP Display
ZA Clr Cnts SO Set Comm. Rpts SR Set Comm. Rate SP Set
SHELF CONFIGURATION LINE CARDS
DC Display DL Display Table DD Disp Config
SC Set CL Copy Config SL Set Config
MAP TABLE MAP MATRIX
DT Display DN Disp. Wrking DM Display
ST Edit SN Set Wrking SM Edit CM Copy
CLOCK SOURCE DIAGNOSTICS
DS Display SS Set OL Line Card OD T1-CSU
PASSWORDS PERFORMANCE
LO Logout SW Install PM FDL Monitor SB Set Error Rate
DW Display EW Erase DH Alarm History ZH Clr Alm History
Figure 4-2. CCU System Access Screen
To access the Main Menu with an Advanced Multiplexer Control Unit (AMCU), type ? and [Enter], and
the AMCU Main Menu will appear (depending upon the user password level), as shown in Figures 4-3, 4-
4 and 4-5. For more information, see the password command sections included later in this chapter.
