Chapter 4. Configuration and Operation
135
PM - FDL Monitor
If a Facility Data Link Processor (FDLP) is included in the multiplexer, enter PM to begin Performance
Monitoring, as shown in Figure 4-37. For more detail on this function, refer to the FDLP User’s Manual.
] PM
10:40:23--------------- [ PERFORMANCE MONITOR ]--------------- 03/08/95
Select Direction Select Side AT&T/ANSI
A) T1-1 D) User G) AT&T
B) T1-2 E) Network H) ANSI
C) Both F) Both I) Both
[ T1-1 ] [ User ] [ AT&T/ANSI T1-1 & None T1-2 ]
Screen Reports Clear Counters Printer Reports
0) Current Status 4) ESF Errors 6) ESF Error Counts
1) 1 Hour 5) Others 7) 1 Hour
2) 24 Hour 8) 24 Hour
3) ANSI 9) ANSI
Logging of Network Messages Network May Reset User Counters
L) Disable P) Disable
M) Enable With Data R) Enable
N) Enable Without Data [ T1-1 Enabled & T1-2 Enabled ]
[ T1-1 Disabled & T1-2 Disabled ]
S) Serial Port Setup
Q) Quit : Q
Figure 4-37. Performance Monitor
