PowerConnect B-Series FCX Web Management Interface User Guide 109
53-1002268-01
Configuring a management port
4
Configuring a management port
Select Configure > Port > Management to configure a management port.
FIGURE 88 Configure Management Port
Click Apply to save the configuration or click Reset to undo changes. Select Status of the port and
click Apply. The change has been made message appears at the top indicating the change.
The Configure Management Port display contains the following information.
Click Show Management to view the details of Management configuration.
Management port name The name of the management port.
MAC Address The MAC address of the management port
Status Allows you to enable or disable the management port.
To Next Page
