PowerConnect B-Series FCX Web Management Interface User Guide 9
53-1002268-01
Monitoring the device
3
Monitoring the device
Select Monitor > Device to view the device information table.
FIGURE 8 Monitoring the device Information
Click Display and select the unit to view the information for any device in an IronStack
The Device Information display contains the following information.
Stack Unit ID Number of the unit within a stack (1-8).
Role Active, Standby, or Member.
System Up Time Amount of time the system has been running since the last reboot.
Running Image Version Software version currently running and some details on the version.
Flash Primary Image
Version
Release number and size of the software loaded on the primary flash.
Flash Secondary Image
Version
Release number and size of the software loaded on the secondary flash.
Boot Image Version Release number and size of the boot image.
