10 PowerConnect B-Series FCX Web Management Interface User Guide
53-1002268-01
Monitoring flash information
3
Monitoring flash information
Stacking system behavior is defined by the runtime configuration, which is stored in a flash file
called startup-config.txt. During bootup, the system reads and applies the startup-config.txt file to
the runtime configuration.
Select Monitor > Flash, to view the flash information.
FIGURE 9 Monitoring the flash Information
The Flash Information window contains the following information.
Temperature In addition to the actual temperature, the color of the degrees provides a visual
indicator for the device:
• Green – The temperature is within the normal operating range.
• Orange – The temperature has reached the warning level.
• Red – The temperature has reached the shutdown level.
CPU Utilization Percentage of CPU being used by the device.
Serial Number The serial number of the device.
Power Supply 1 The status of the primary power supply.
Power Supply 2 The status of the secondary power supply, if present.
Fan
(There is an entry for
each fan in the device)
The status of the cooling fans.
